Welding Project Plans Drawings Lambo (DXF, PDF)

$299.00

Digital

Digital Project –Lambo This is a digital product (no physical item) designed for DIY metal sculpture making. You’ll need access to a CNC metal cutting machine or tools for manual cutting using stencils (like an angle grinder). Parts are bent using a bending machine or by hand, then welded together following the step-by-step instructions. Optional finishing includes sanding and painting. This is a large project requiring a lot of material, the project cannot be reduced. To produce wheels, you need to be able to make cylinders and cones of a given size from sheet metal. ⚠️ Note: You are allowed to produce and sell only finished sculptures. Resale and distribution of drawings, files, assembly kits based on these files is strictly prohibited. 📐 Project Details: • Material: Steel, 1,5 and 3 mm thick (Both thicknesses are needed) • Bending radius: 1 mm • Total weight: ~470 kg • Parts: 336 pieces Fasteners: • Nut M8 DIN 985 - 20 pcs. • Nut M8 DIN 934 - 20 pcs. • Bolt M8x14 - 20 pcs. • Nut M16 - 20 pcs. • Bolt M16x170 - 20 pcs. Number of sheets: • for 2400x1200 ...1,5mm - 15 sheets, ...3mm - 2 sheets • for 2500x1250 ...1,5mm - 14 sheets, ...3mm - 2 sheets • for 3000x1500 ...1,5mm - 10 sheets, ...3mm - 1 sheet Files included: • DXF files (separate and combined on one sheet) • Drawings: 115 pages PDF • Assembly Instructions: 59 pages PDF Final sculpture size (L×W×H): 4908 × 2285 × 1133 mm File options: With and without engraving • Cutting layer: "Cut" ✂️ • Engraving layer: "Engrav" 🔧 • Engraving is on the inner side, bend lines are on the outer side 🛠 Extras & Notes: • 3D models (STP format, unassembled, excluding mirrored parts) available for an additional fee • If your machine requires G-code, please contact me before purchasing – I’ll send you a sample file • If you can’t download the files, I’ll send them via email within 24 hours • This project is sold exclusively by me — beware of scammers. ⚠️ Thank you, and good luck with your project!
